Rockwell Automation 21G PowerFlex 750-Series AC Drives Programming Manual User Manual
Page 73

Rockwell Automation Publication 750-PM001J-EN-P - October 2014
73
Drive Port 0 Parameters
Chapter 3
FEEDBA
CK & I/O
Digin F
u
nc
ti
on
s
176
DI HOA Start
Digital Input Hand-Off-Auto Start
A start for a hand-off-auto configuration. A delay filter allows the start and stop signals
to come from the same circuit.
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
177
DI MOP Inc
Digital Input Motor Operated Potentiometer Increment
Assigns a digital input used to increment the MOP speed reference.
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
178
DI MOP Dec
Digital Input Motor Operated Potentiometer Decrement
Assigns a digital input used to decrement the MOP speed reference.
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
179
DI Accel 2
Digital Input Acceleration 2
Assigns a digital input used to activate P536 [Accel Time 2].
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
180
DI Decel 2
Digital Input Deceleration 2
Assigns a digital input used to activate P538 [Decel Time 2].
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
181
182
DI SpTqPs Sel 0
DI SpTqPs Sel 1
Digital Input Speed Torque Position Select n
Assigns digital inputs used to select between speed, torque, and position modes.
Refer to position B5 in the block diagram on
for details.
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
185
DI Stop Mode B
Digital Input Stop Mode B
Assigns a digital input used to activate P371 [Stop Mode B].
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
186
DI BusReg Mode B
Digital Input Bus Regulation Mode B
Assigns a digital input used to activate P373 [Bus Reg Mode B].
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
187
DI PwrLoss ModeB
Digital Input Power Loss Mode B
Assigns a digital input used to activate P453 [Pwr Loss Mode B].
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
188
DI Pwr Loss
Digital Input Power Loss
Assigns a digital input used to force a power loss condition.
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
189
DI Precharge
Digital Input Precharge
Assigns a digital input used to force the drive into precharge (often used in Common DC
input applications). A low signal forces the drive into precharge.
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
190
DI Prchrg Seal
Digital Input Precharge Seal
Assigns a digital input used to force a unique fault when an external precharge circuit
opens.
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
Fi
le
Grou
p
No.
Display Name
Full Name
Description
Values
Re
ad
-W
ri
te
Da
ta
T
ype
Auto Reference Source
(Parameter)
Input Status (1 = Input Actuated)
DI Speed Sel 0
DI Speed Sel 1
P309
0
0
P310
0
1
P311
1
0
P312
1
1
