Port 10 and Port 11 Parameters
Chapter 4
Fil
e
Gr
ou
p
No.
Display Name
Full Name
Description
Values
Re
ad
-Write
Da
ta T
ype
IN
VERTER N
Meteri
ng
115
215
315
I1 U Phase Curr
I2 U Phase Curr
I3 U Phase Curr
Inverter n U Phase Current
Output current present through terminal T1 (U phase) of inverter n.
Units:
Default:
Min/Max:
Amps
0.0
–/+3000.0
RO
Real
116
216
316
I1 V Phase Curr
I2 V Phase Curr
I3 V Phase Curr
Inverter n V Phase Current
Output current present through terminal T2 (V phase) of inverter n.
Units:
Default:
Min/Max:
Amps
0.0
–/+3000.0
RO
Real
117
217
317
I1 W Phase Curr
I2 W Phase Curr
I3 W Phase Curr
Inverter n W Phase Current
Output current present through terminal T3 (W phase) of inverter n.
Units:
Default:
Min/Max:
Amps
0.0
–/+3000.0
RO
Real
118
218
318
I1 Gnd Current
I2 Gnd Current
I3 Gnd Current
Inverter n Ground Current
Ground current of the AC output to a motor. The value is calculated based on the output
currents (U, V, and W phases) for inverter n. When the three phases are balanced, the
ground current is ideally close to zero.
Units:
Default:
Min/Max:
Amps
0.0
–/+3000.0
RO
Real
119
219
319
I1 DC Bus Volt
I2 DC Bus Volt
I3 DC Bus Volt
Inverter n DC Bus Voltage
DC bus voltage measured by inverter n.
Units:
Default:
Min/Max:
V DC
0.00
0.00 / 1200.00
RO
Real
120
220
320
I1 Heatsink Temp
I2 Heatsink Temp
I3 Heatsink Temp
Inverter n Heatsink Temperature
Temperature of the heatsink for inverter n.
Units:
Default:
Min/Max:
DegC
0.0
–/+200.0
RO
Real
121
221
321
I1 IGBT Temp
I2 IGBT Temp
I3 IGBT Temp
Inverter n IGBT Temperature
IGBT junction temperature of inverter n.
Units:
Default:
Min/Max:
DegC
0.0
–/+200.0
RO
Real
124
224
324
I1 HSFan Speed
I2 HSFan Speed
I3 HSFan Speed
Inverter n Heatsink Fan Speed
The measured speed of the heatsink fan for inverter n.
Units:
Default:
Min/Max:
RPM
0.0
0.0 / 7200.0
RO
Real
125
225
325
I1 InFan 1 Speed
I2 InFan 1 Speed
I3 InFan 1 Speed
Inverter n Internal Fan 1 Speed
The measured speed of internal stirring fan 1 for inverter n.
Units:
Default:
Min/Max:
RPM
0.0
0.0 / 7200.0
RO
Real
126
226
326
I1 InFan 2 Speed
I2 InFan 2 Speed
I3 InFan 2 Speed
Inverter n Internal Fan 2 Speed
The measured speed of internal stirring fan 2 for inverter n.
Units:
Default:
Min/Max:
RPM
0.0
0.0 / 7200.0
RO
Real
