Rockwell Automation 21G PowerFlex 750-Series AC Drives Programming Manual User Manual
Page 519
Rockwell Automation Publication 750-PM001J-EN-P - October 2014
519
Integrated Motion on EtherNet/IP
Appendix E
834
Psn Out Fltr BW
2624
A40
Psn Out Fltr BW
970
Testpoint Sel 1
2661
A65
Testpoint Sel 1
971
Testpoint Fval 1
2662
A66
Testpoint Fval 1
972
Testpoint Lval 1
2663
A67
Testpoint Lval 1
974
Testpoint Sel 2
2664
A68
Testpoint Sel 2
975
Testpoint Fval 2
2665
A69
Testpoint Fval 2
976
Testpoint Lval 2
2666
A6A
Testpoint Lval 2
978
Testpoint Sel 3
2667
A6B
Testpoint Sel 3
979
Testpoint Fval 3
2668
A6C
Testpoint Fval 3
980
Testpoint Lval 3
2669
A6D
Testpoint Lval 3
982
Testpoint Sel 4
2670
A6F
Testpoint Sel 4
983
Testpoint Fval 4
2671
A6F
Testpoint Fval 4
984
Testpoint Lval 4
2672
A70
Testpoint Lval 4
1035
PkDtct Stpt Real
2673
A71
PkDtct Stpt Real
1036
PkDtct Stpt DInt
2674
A72
PkDtct Stpt DInt
1037
PkDtct1 In Sel
2675
A73
PkDtct1 In Sel
1038
PkDtct1PresetSel
2676
A74
PkDtct1PresetSel
1039
Peak1 Cfg
2677
A75
Peak1 Cfg
1040
Peak 1 Change
2678
A76
Peak 1 Change
1041
PeakDetect1 Out
2679
A77
PeakDetect1 Out
1042
PkDtct2 In Sel
2680
A78
PkDtct2 In Sel
1043
PkDtct2PresetSel
2681
A79
PkDtct2PresetSel
1044
Peak2 Cfg
2682
A7A
Peak2 Cfg
1045
Peak 2 Change
2683
A7B
Peak 2 Change
1046
PeakDetect2 Out
2684
A7C
PeakDetect2 Out
1535
VB Config
2704
A90
VB Config
1536
VB Status
2705
A91
VB Status
1537
VB Voltage
2706
A92
VB Voltage
1538
VB Time
2707
A93
VB Time
1539
VB Minimum
2708
A94
VB Minimum
1540
VB Maximum
2709
A95
VB Maximum
1541
VB Accel Rate
2710
A96
VB Accel Rate
1542
VB Decel Rate
2711
A97
VB Decel Rate
1543
VB Frequency
2712
A98
VB Frequency
1544
VB Min Freq
2713
A99
VB Min Freq
1545
VB Flux Thresh
2714
A9A
VB Flux Thresh
1546
VB Flux Lag Freq
2715
A9B
VB Flux Lag Freq
1547
VB Filt Flux Cur
2716
A9C
VB Filt Flux Cur
1548
VB Current Rate
2717
A9D
VB Current Rate
1549
VB Current Hyst
2718
A9E
VB Current Hyst
1550
VB Cur Thresh
2719
A9F
VB Cur Thresh
1551
VB Rate Lag Freq
2720
AA0
VB Rate Lag Freq
Drive
Integrated Motion
Parameter No.
Parameter Name
Base 10
Base 16
Enhanced Attribute
