Rockwell Automation Publication 750-PM001J-EN-P - October 2014 37
Parameter Organization Chapter 2
Diagnostics Status Speed Ref Source 930
Last StartSource 931
Last Stop Source 932
Start Inhibits 933
Last StrtInhibit 934
Drive Status 1 935
Drive Status 2 936
Condition Sts 1 937
Drive OL Count 940
IGBT Temp Pct 941
IGBT Temp C 942
Drive Temp Pct 943
Drive Temp C 944
At Limit Status 945
Safety Port Sts 946
Fault/Alarm Info Minor Flt Cfg 950
Last Fault Code 951
Fault Status A 952
Fault Status B 953
Status1 at Fault 954
Status2 at Fault 955
Fault Frequency 956
Fault Amps 957
Fault Bus Volts 958
Alarm Status A 959
Alarm Status B 960
Type 2 Alarms 961
AlarmA at Fault 962
AlarmB at Fault 963
Testpoints Testpoint Sel 1 970
Testpoint Fval 1 971
Testpoint Lval 1 972
Testpoint Sel 2 974
Testpoint Fval 2 975
Testpoint Lval 2 976
Testpoint Sel 3 978
Testpoint Fval 3 979
Testpoint Lval 3 980
Testpoint Sel 4 982
Testpoint Fval 4 983
Testpoint Lval 4 984
Peak Detection 755 PkDtct Stpt Real 1035
PkDtct Stpt DInt 1036
PkDtct1 In Sel 1037
PkDtct1PresetSel 1038
Peak1 Cfg 1039
Peak 1 Change 1040
PeakDetect1 Out 1041
PkDtct2 In Sel 1042
PkDtct2PresetSel 1043
Peak2 Cfg 1044
Peak 2 Change 1045
PeakDetect2 Out 1046
Applications Process PID PID Cfg 1065
PID Control 1066
PID Ref Sel 1067
PID Ref AnlgHi 1068
PID Ref AnlgLo 1069
PID Setpoint 1070
PID Ref Mult 1071
PID Fdbk Sel 1072
PID Fdbk AnlgHi 1073
PID Fdbk AnlgLo 1074
PID FBLoss SpSel 1075
PID FBLoss TqSel 1076
PID Fdbk 1077
PID Fdbk Mult 1078
PID Output Sel 1079
PID Output Mult 1080
PID Upper Limit 1081
PID Lower Limit 1082
PID Deadband 1083
PID LP Filter BW 1084
PID Preload 1085
PID Prop Gain 1086
PID Int Time 1087
PID Deriv Time 1088
PID Status 1089
PID Ref Meter 1090
PID Fdbk Meter 1091
PID Error Meter 1092
PID Output Meter 1093
Torque Prove 755 Trq Prove Cfg 1100
Trq Prove Setup 1101
DI FloatMicroPsn 1102
Trq Prove Status 1103
Trq Lmt SlewRate 1104
Speed Dev Band 1105
SpdBand Intgrtr 1106
Brk Release Time 1107
Brk Set Time 1108
Brk Alarm Travel 1109
Brk Slip Count 1110
Float Tolerance 1111
MicroPsnScalePct 1112
ZeroSpdFloatTime 1113
Brake Test Torq 755 1114
Fibers Function Fiber Control 1120
Fiber Status 1121
Sync Time 1122
Traverse Inc 1123
Traverse Dec 1124
Max Traverse 1125
P Jump 1126 DI Fiber SyncEna 1129
DI Fiber TravDis 1130
Adjustable Vltg Adj Vltg Config 1131
Adj Vltg Select 1133
Adj Vltg Ref Hi 1134
Adj Vltg Ref Lo 1135
Adj Vltg TrimSel 1136
Adj Vltg Trim Hi 1137
Adj Vltg Trim Lo 1138
Adj Vltg Command 1139
Adj Vltg AccTime 1140
Adj Vltg DecTime 1141
Adj Vltg Preset1 1142
Adj Vltg Preset2 1143
Adj Vltg Preset3 1144
Adj Vltg Preset4 1145
Adj Vltg Preset5 1146
Adj Vltg Preset6 1147
Adj Vltg Preset7 1148
Adj Vltg RefMult 1149
Adj Vltg Scurve 1150
Adj Vltg TrimPct 1151
Min Adj Voltage 1152
Dead Time Comp 1153
DC Offset Ctrl 1154
Pump Jack Rod Speed 1165
Rod Torque 1166
Rod Speed Cmd 1167
TorqAlarm Action 1168
TorqAlarm Config 1169
TorqAlarm Dwell 1170
TorqAlarm Level 1171
TorqAlm Timeout 1172
TorqAlarm TOActn 1173
Total Gear Ratio 1174
Max Rod Speed 1175
Max Rod Torque 1176
Min Rod Speed 1177
Motor Sheave 1178
OilWell Pump Cfg 1179
PCP Pump Sheave 1180
Gearbox Limit 1181
Gearbox Rating 1182
Gearbox Ratio 1183
Gearbox Sheave 1184
Pump Off Pump Off Config 1187
Pump Off Setup 1188
Pump Off Action 1189
Pump Off Control 1190
Pump Off Status 1191
Pump Cycle Store 1192
Set Top ofStroke 1193
Torque Setpoint 1194
Pump Off Level 1195
Pump Off Speed 1196
Pump Off Time 1197
Pct Cycle Torque 1198
Pct Lift Torque 1199
Pct Drop Torque 1200
Stroke Pos Count 1201
Stroke Per Min 1202
Pump Off Count 1203
PumpOff SleepCnt 1204
Day Stroke Count 1205
DI PumpOff Disbl 1206
Pump OffSleepLvl 1207
File Group Parameters
Diagnostics
Applica
tions
