Rockwell Automation Publication 750-PM001J-EN-P - October 2014
71
Drive Port 0 Parameters
Chapter 3
Fi
le
Grou
p
No.
Display Name
Full Name
Description
Values
Re
ad
-W
ri
te
Da
ta
T
ype
FEEDBA
CK & I/O
Digi
n F
u
n
cti
ons
150
Digital In Cfg
Digital Input Configure
Defines operation for DI Run type parameters.
Run Edge (0) – Control function requires a rising edge (open to close transition) in order
for the drive to run.
Run Level (1) – Provides a run level input. Does not require a transition for enable or
fault, but a transition is required for a stop.
When set to 1 “Run Level” the absence of a run command is indicated as a stop asserted
and parameter 935 [Drive Status 1] Bit 0 will be low.
Default:
Options:
0 – Run Edge
0 – Run Edge
1 – Run Level
RW 32-bit
Integer
155
DI Enable
Digital Input Enable
Assigns a digital input used to enable the drive.
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
156
DI Clear Fault
Digital Input Clear Fault
Assigns a digital input used to clear faults.
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
157
DI Aux Fault
Digital Input Auxiliary Fault
Assigns a digital input used to force an external auxiliary fault.
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
158
DI Stop
Digital Input Stop
Assigns a digital input used to issue a stop command.
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
159
DI Cur Lmt Stop
Digital Input Current Limit Stop
Assigns a digital input used to perform a current limited stop.
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
160
DI Coast Stop
Digital Input Coast Stop
Assigns a digital input used to perform a coast-to-stop.
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
161
DI Start
Digital Input Start
Assigns a digital input used to start the drive (3-wire control).
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
162
DI Fwd Reverse
Digital Input Forward Reverse
Assigns a digital input used to command reverse direction.
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
163
DI Run
Digital Input Run
Assigns a digital input used to run the drive (2-wire control).
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
164
DI Run Forward
Digital Input Run Forward
Assigns a digital input used to run the drive (2 wire control) and command forward
direction.
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
ATTENTION: Equipment damage and/or personal injury may result if this parameter is used in an inappropriate
application. Do not use this function without considering applicable local, national and international codes, standards,
regulations, or industry guidelines.
