104 Rockwell Automation Publication 750-PM001J-EN-P - October 2014
Chapter 3 Drive Port 0 Parameters
Fi
le
Grou
p
No. Display Name
Full Name
Description Values
Re
ad
-W
ri
te
Da
ta
T
ype
PR
OTEC
TI
ON
Grou
n
d F
au
lt
466 Ground Warn Actn
Ground Warning Action
Selects the action to take when a ground current event is detected.
The Ground Warning feature detects a ground current that exceeds the level set in P467
[Ground Warn Lvl].
An alarm is displayed until the ground current falls below the level set in P467 [Ground
Warn Lvl] while the drive continues to run.
A fault will stop the drive. A fault cannot be cleared until the ground current is below the
level set in P467 [Ground Warn Lvl].
“Ignore” (0) – No action is taken.
“Alarm” (1) – Type 1 alarm indicated.
“Flt Minor” (2) – Minor fault indicated. If running, drive continues to run.
Enable with P950 [Minor Flt Cfg]. If not enabled, acts like a major fault.
“FltCoastStop” (3) – Major fault indicated. Coast to Stop.
“Flt RampStop” (4) – Major fault indicated. Ramp to Stop.
“Flt CL Stop” (5) – Major fault indicated. Current Limit Stop. Default:
Options: 0 = “Ignore”
0 = “Ignore”
1 = “Alarm”
2 = “Flt Minor”
3 = “FltCoastStop”
4 = “Flt RampStop”
5 = “Flt CL Stop” RW 32-bit
Integer
467 Ground Warn Lvl
Ground Warning Level
Sets the level at which a ground warning alarm will occur. Units:
Default:
Min/Max: Amps
4.00
1.00 / 5.00 RW Real
