Rockwell Automation Publication 750-PM001J-EN-P - October 2014 351
Troubleshooting Chapter 6
xx023 Ch0 AccCode Err Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Incorrect access code
xx024 Ch0 FieldSizeErr Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Size of data field stated cannot be changed
xx025 Ch0 Address Err Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Word address stated is outside data field
xx026 Ch0 FieldAcc Err Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Access to non-existent data field
xx028 Ch0 SiTurnPsnErr Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Single turn position unreliable
xx029 Ch0 MulTrnPsnErr Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Multiple turn position unreliable
xx036 Ch0 AnalVal Err Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Analog value error (process data)
xx037 Ch0 SendCurr Err Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Transmitter current critical (dirt, broken transmitter)
xx038 Ch0 EncTemp Err Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Encoder temperature critical
xx039 Ch0 Speed Err Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Speed too high, no position formation possible
xx040 Ch0 General Err Configurable P9
[FB0 Loss Cfg] Error reported by a Encoder on Channel 0 with BiSS Interface - An error
bit of the BiSS Single Cycle Data is set
xx046 Ch0 LED Curr Err Configurable P9
[FB0 Loss Cfg] Error reported by a Encoder on Channel 0 with BiSS Interface - LED
current out of control range
xx047 Ch0 ExMulTurnErr Configurable P9
[FB0 Loss Cfg] Error reported by a Encoder on Channel 0 with BiSS Interface - External
multiturn error
xx048 Ch0 PsnCode Err Configurable P9
[FB0 Loss Cfg] Error reported by a Encoder on Channel 0 with BiSS Interface - Position
code error (single step error)
xx049 Ch0 Config Err Configurable P9
[FB0 Loss Cfg] Error reported by a Encoder on Channel 0 with BiSS Interface - failure
configuring interface
xx050 Ch0 PsnVal Err Configurable P9
[FB0 Loss Cfg] Error reported by a Encoder on Channel 0 with BiSS Interface - Position
data not valid
xx051 Ch0 SerialComErr Configurable P9
[FB0 Loss Cfg] Error reported by a Encoder on Channel 0 with BiSS Interface - Serial
interface failure
xx052 Ch0 Ext Failure Configurable P9
[FB0 Loss Cfg] Error reported by a Encoder on Channel 0 with BiSS Interface - External
failure over NERR
xx053 Ch0 Temp Exc Err Configurable P9
[FB0 Loss Cfg] Error reported by a Encoder on Channel 0 with BiSS Interface -
Temperature out of defined range
xx058 Module Defaulted Fault Coast Parameter values for this encoder have been reset to their default
settings.
xx064 Ch0 OutOfRailErr Configurable P9
[FB0 Loss Cfg] Error reported by a linear Stahl encoder on Channel 0 - Rail is no longer
present between the read head
xx068 Ch0 Read Head 1 Configurable P9
[FB0 Loss Cfg] Error reported by a linear Stahl encoder on Channel 0 - Indicates that the
read head must be cleaned or installed correctly
xx069 Ch0 Read Head 2 Configurable P9
[FB0 Loss Cfg] Error reported by a linear Stahl encoder on Channel 0 - Indicates that the
read head must be cleaned or installed correctly
xx070 Ch0 RAM Error Configurable P9
[FB0 Loss Cfg] Error reported by a linear Stahl encoder on Channel 0 - Indicates a RAM
error. Reading head needs to be repaired
xx071 Ch0 EPROM Error Configurable P9
[FB0 Loss Cfg] Error reported by a linear Stahl encoder on Channel 0 - Indicates a
EPROM error. Reading head needs to be repaired
Event
No.
(1)
Fault/Alarm Text Type Fault
Action Configuration Param Auto
Reset Description
