Drive Port 0 Parameters Chapter 3
DI
AG
N
O
STICS
Fa
ul
t/
A
la
rm
In
fo
955 Status2 at Fault
Status 2 at Fault RO 32-bit
Integer
Captures and displays P936 [Drive Status 2] bit pattern at the time of the last fault.
See parameter 936 [Drive Status 2] for bit descriptions.
956 Fault Frequency
Fault Frequency
Captures and displays the current value of P1 [Output Frequency], in Hertz, at the time
of the last fault. Setting P300 [Speed Units] to option 1 “RPM” does not affect this
parameter.
For some faults, the value captured in this parameter may not match peak/low at time
of fault due to data latency. Units:
Default:
Min/Max: Hz
0.00
–/+ 650.00 RO Real
957 Fault Amps
Fault Amps
Captures and displays the current value of P7 [Output Current], in Amps, at the time of
the last fault.
For some faults, the value captured in this parameter may not match peak/low at time
of fault due to data latency. Units:
Default:
Min/Max: Amps
0.00
0.00 / P21 [Rated Amps] x 2 RO Real
958 Fault Bus Volts
Fault Bus Volts
Captures and displays the current value of P11 [DC Bus Volts], in Volts DC, at the time of
the last fault.
For some faults, the value captured in this parameter may not match peak/low at time
of fault due to data latency. Units:
Default:
Min/Max: V DC
0.00
0.00 / P20 [Rated Volts] x 2 RO Real
959 Alarm Status A
Alarm Status A RO 32-bit
Integer
Indicates the occurrence of conditions that have been configured as alarms. These events are from 937 [Condition Sts 1].
See parameter 937 [Condition Sts 1] for bit descriptions.
