154 Rockwell Automation Publication 750-PM001J-EN-P - October 2014
Chapter 3 Drive Port 0 Parameters
Drive (Port 0) Diagnostics File
Fi
le
Grou
p
No. Display Name
Full Name
Description Values
Re
ad
-W
ri
te
Da
ta
T
ype
DIA
G
NOSTICS
Sta
tus
930 Speed Ref Source
Speed Reference Source
Indicates the currently selected source for value displayed in P593 [Limited Spd Ref].
The Speed Reference Source displays the parameter number that is supplying the speed
reference. For example, if Speed Reference Source contains the value 546, then P546
[Spd Ref A Stpt] is the source of the speed reference. Default:
Min/Max: 0
0 / 159999 RO 32-bit
Integer
931 Last StartSource
Last Start Source
Displays the source that initiated the most recent start sequence. All bits in this
parameter are refreshed each time the drive receives a start command. Default:
Options: 0 = Read Only
0 = “Pwr Removed”
1-6 = “Port 1-6”
7 = “Digital In”
8 = “Sleep”
9 = “Jog”
10 = “Profiling”
11 = “AutoRestart”
12 = “Pwr Up Start”
13 = “Fault”
14 = “Enable”
15 = “Autotune”
16 = “Precharge”
17 = “Safety”
18 = “Fast Stop”
19 = “Port 13”
20 = “Port 14” RO 32-bit
Integer
932 Last Stop Source
Last Stop Source
Displays the source that initiated the most recent stop sequence. All bits in this
parameter are refreshed each time the drive receives a stop command. Default:
Options: 0 = Read Only
0 = “Pwr Removed”
1-6 = “Port 1-6”
7 = “Digital In”
8 = “Sleep”
9 = “Jog”
10 = “Profiling”
11 = “AutoRestart”
12 = “Pwr Up Start”
13 = “Fault”
14 = “Enable”
15 = “Autotune”
16 = “Precharge”
17 = “Safety”
18 = “Fast Stop”
19 = “Port 13”
20 = “Port 14” RO 32-bit
Integer
