Rockwell Automation 21G PowerFlex 750-Series AC Drives Programming Manual User Manual
Page 72

72
Rockwell Automation Publication 750-PM001J-EN-P - October 2014
Chapter 3
Drive Port 0 Parameters
FEEDBA
CK &
I/O
Digi
n F
u
n
cti
ons
165
DI Run Reverse
Digital Input Run Reverse
Assigns a digital input used to run the drive (2 wire control) and command reverse
direction.
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
166
DI Jog 1
Digital Input Jog 1
Assigns a digital input used to jog the drive at the speed of P556 [Jog Speed 1].
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
167
DI Jog 1 Forward
Digital Input Jog 1 Forward
Assigns a digital input used to jog the drive in the forward direction at the speed of P556
[Jog Speed 1].
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
168
DI Jog 1 Reverse
Digital Input Jog 1 Reverse
Assigns a digital input used to jog the drive in the reverse direction at the speed of P556
[Jog Speed 1].
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
169
DI Jog 2
Digital Input Jog 2
Assigns a digital input used to jog the drive at the speed of P557 [Jog Speed 2].
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
170
DI Jog 2 Forward
Digital Input Jog 2 Forward
Assigns a digital input used to jog the drive in the forward direction at the speed of P557
[Jog Speed 2].
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
171
DI Jog 2 Reverse
Digital Input Jog 2 Reverse
Assigns a digital input used to jog the drive in the reverse direction at the speed of P557
[Jog Speed 2].
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
172
DI Manual Ctrl
Digital Input Manual Control
Assigns a digital input used to command manual control. Start, jog, and direction are
under the digital input’s exclusive control. P563 [DI ManRef Sel] is the source of the
speed reference unless overwritten by P328 [Alt Man Ref Sel].
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
173
174
175
DI Speed Sel 0
DI Speed Sel 1
DI Speed Sel 2
Digital Input Speed Select n
Assigns digital inputs used to select between speed references as follows:
Default:
Min/Max:
0.00
0.00 / 159999.15
RW 32-bit
Integer
Fi
le
Grou
p
No.
Display Name
Full Name
Description
Values
Re
ad
-W
ri
te
Da
ta
T
ype
Input Status (1 = Input Actuated)
Auto Reference Source
(Parameter)
DI Speed Sel 2
DI Speed Sel 1
DI Speed Sel 0
0
0
0
Reference A (P545)
0
0
1
Reference A (P545)
0
1
0
Reference B (P550)
0
1
1
Preset Speed 3 (P573)
1
0
0
Preset Speed 4 (P574)
1
0
1
Preset Speed 5 (P575)
1
1
0
Preset Speed 6 (P576)
1
1
1
Preset Speed 7 (P577)
