332 Rockwell Automation Publication 750-PM001J-EN-P - October 2014
Chapter 6 Troubleshooting
10131
10231
10331 I1 Fault Q Full
I2 Fault Q Full
I3 Fault Q Full Resettable
Fault Coast The fault queue is full. There are at least three other faults in the queue.
Troubleshooting and clearing the existing faults will make room for
additional faults in the queue (if any).
This fault may occur during a normal power down sequence.
10132
10232
10332 I1 Incompat PS
I2 Incompat PS
I3 Incompat PS Resettable
Fault Coast The drive has detected an incompatible power supply for the drive AC
input rating.
• Check the power supply and replace it if incorrect.
• If the power supply is correct, re-flash the control board.
• If this problem persists, replace the inverter power supply board or
power layer interface board.
10134
10234
10334 I1 UBrd Fault
I2 UBrd Fault
I3 UBrd Fault Resettable
Fault Coast The power supply on the U, V, or W phase gate driver board has failed.
• If this fault occurred on this phase only, replace the appropriate gate
driver board.
• If this fault occurred on all three phases, check the 24V power supply
on the inverter power supply board that feeds the gate driver boards
and replace the inverter power supply board if necessary.
10135
10235
10335 I1 VBrd Fault
I2 VBrd Fault
I3 VBrd Fault
10136
10236
10336 I1 WBrd Fault
I2 WBrd Fault
I3 WBrd Fault
10137
10237
10337 I1 Cur Offset U
I2 Cur Offset U
I3 Cur Offset U Alarm 1 The current sensor for the U, V, or W phase is not reading zero (off by
more than 1% of the inverter rated current), while the drive is not
running.
• Check the current sensor’s offset reading inverter testpoint and
power supply. If necessary, replace the current sensor.
• If this problem persists, replace the inverter power supply board and/
or the power layer interface board.
10138
10238
10338 I1 Cur Offset V
I2 Cur Offset V
I3 Cur Offset V
10139
10239
10339 I1 Cur Offset W
I2 Cur Offset W
I3 Cur Offset W
Event
No. Fault/Alarm Text Type Fault
Action Configuration
Parameter Auto
Reset Description/Action(s)
