Drive Port 0 Parameters
Chapter 3
MO
TO
R
C
O
NT
ROL
Mt
r Ctr
l Opti
on
s
42
Bus Utilization
Bus Utilization
The maximum allowed bus voltage utilization for the Motor Control.
Do not change this value without consulting Technical Support. Higher values may
result in control instability or over-current faults.
Units:
Default:
Min/Max:
%
95.00
85.00 / 100.00
RW Real
43
Flux Up Enable
Flux Up Enable
Manual (0) – Flux is established for P44 [Flux Up Time] before initial acceleration.
Automatic (1) – Flux is established for a calculated time period based on motor
nameplate data before acceleration. P44 [Flux Up Time] is not used.
Default:
Options:
1 – Automatic
0 – Manual
1 – Automatic
RW 32-bit
Integer
44
Flux Up Time
Flux Up Time
The amount of time the drive will use to try to achieve full motor stator flux. When a
Start command is issued, DC current at P26 [Motor NP Amps] level is used to build stator
flux before accelerating.
Units:
Default:
Min/Max:
Secs
0.0000
0.0000 / 5.0000
RW Real
45
Flux Down Ki
Flux Down Ki
The integral term used in the voltage regulator which controls the removal of flux in the
motor.
Default:
Min/Max:
0.20
0.00 / 100.00
RW Real
46
Flux Down Kp
Flux Down Kp
The proportional term used in the voltage regulator which controls the removal of flux in
the motor.
Default:
Min/Max:
150.0
0.0 / 10000.0
RW Real
47
Econ At Ref Ki
Economize At Reference Ki
Integral gain that determines the response of the output voltage when P35 [Motor Ctrl
Mode] option 2 “Induct Econ”
is selected and the output frequency is at its reference.
Default:
Min/Max:
305.0
0.0 / 100000.0
RW Real
48
Econ AccDec Ki
Economize Acceleration/Deceleration Ki
Integral gain that determines the response of the output voltage when P35 [Motor Ctrl
Mode] option 2 “Induct Econ” is selected and the output frequency is either accelerating
or decelerating to a reference.
Default:
Min/Max:
200.0
0.0 / 100000.0
RW Real
49
Econ AccDec Kp
Economize Acceleration/Deceleration Kp
Proportional gain that determines the response of the output voltage when P35 [Motor
Ctrl Mode] option 2 “Induct Econ” is selected and the output frequency is either
accelerating or decelerating to a reference.
Units:
Default:
Min/Max:
V/A
100.0
0.0 / 1000000.0
RW Real
50
Stability Filter
Stability Filter
The filter time constant for the angle and voltage stability control.
Units:
Default:
Min/Max:
Secs
5162.22
0.00 / 1000000.00
RW Real
51
Stab Volt Gain
Stability Voltage Gain
The gain of the voltage stability control function. Not active when any FV motor control
mode is selected with speed feedback.
Default:
Min/Max:
5322.22
0.00 / 10000000.00
RW Real
52
Stab Angle Gain
Stability Angle Gain
The gain of the electrical angle stability control function. Not active when any FV motor
control mode is selected in P35 [Motor Ctrl Mode] with speed feedback.
Default:
Min/Max:
790.43
0.00 / 10000000.00
RW Real
