Chapter 6 Troubleshooting
Universal Feedback Faults
and Alarms The table below contains a list of universal feedback-specific faults and alarms,
the type of fault or alarm, the action taken when the drive faults, the parameter
used to configure the fault or alarm (if applicable), and a description and action
(where applicable).
Table 23 - Universal Feedback Fault and Alarm Types, Descriptions and Actions
Event
No.
(1)
Fault/Alarm Text Type Fault
Action Configuration Param Auto
Reset Description
xx000 LightSrc Err Configurable P9
[FB0 Loss Cfg] Error reported by Heidenhain Encoder on Channel 0 with EnDat Interface
- Light source failure
xx001 Ch0 SigAmp Err Configurable P9
[FB0 Loss Cfg] Error reported by Heidenhain Encoder on Channel 0 with EnDat Interface
-Signal amplitude error
xx002 Ch0 PsnVal Err Configurable P9
[FB0 Loss Cfg] Error reported by Heidenhain Encoder on Channel 0 with EnDat Interface
- Position value error
xx003 Ch0 OverVolt Err Configurable P9
[FB0 Loss Cfg] Error reported by Heidenhain Encoder on Channel 0 with EnDat Interface
- Overvoltage error
xx004 Ch0 UndVolt Err Configurable P9
[FB0 Loss Cfg] Error reported by Heidenhain Encoder on Channel 0 with EnDat Interface
- Undervoltage error
xx005 Ch0 OverCur Err Configurable P9
[FB0 Loss Cfg] Error reported by Heidenhain Encoder on Channel 0 with EnDat Interface
- Overcurrent error
xx006 Ch0 Battery Err Configurable P9
[FB0 Loss Cfg] Error reported by Heidenhain Encoder on Channel 0 with EnDat Interface
- Battery empty
xx009 Ch0 AnalSig Err Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Analog signals outside specification
xx010 Ch0 IntOfst Err Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Faulty internal angular offset
xx011 Ch0 DataTabl Err Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Data field partitioning table damaged
xx012 Ch0 AnalLim Err Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Analog limit values not available
xx013 Ch0 Int I2C Err Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Internal I2C bus not operational
xx014 Ch0 IntChksm Err Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Internal checksum error
xx015 Ch0 PrgmResetErr Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Encoder reset occurred as a result of program monitoring
xx016 Ch0 CntOvrflwErr Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Counter overflow
xx017 Ch0 Parity Err Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Parity error
xx018 Ch0 Chksum Err Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Checksum of the data transmitted is incorrect
xx019 Ch0 InvCmd Err Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Unknown command code
xx020 Ch0 SendSize Err Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Number of data transmitted is incorrect
xx021 Ch0 CmdArgmt Err Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - Command argument transmitted is not allowed
xx022 Ch0 InvWrtAdrErr Configurable P9
[FB0 Loss Cfg] Error reported by Stegmann Encoder on Channel 0 with Hiperface
Interface - The selected data field must not be written to (invalid write
address)
