Rockwell Automation Publication 750-PM001J-EN-P - October 2014
45
Parameter Organization
Chapter 2
How Option Module
Parameters are Organized
Option module parameters are only available when that option is installed in a
host drive. To view and edit option module parameters, select the port number of
the device you want to access from the Status Screen.
11-Series I/O Modules
Parameter descriptions begin on
.
File
Group
Parameters
11-Series I/O
Host Groups
Digital Inputs
Dig In Sts
1
Dig In Filt Mask
2
Dig In Filt
3
Digital Outputs
Dig Out Sts
5
Dig Out Invert
6
Dig Out Setpoint
7
RO0 Sel
10
RO0 Level Sel
11
RO0 Level
12
RO0 Level CmpSts
13
RO0 On Time
14
RO0 Off Time
15
RO1 Sel
20
TO0 Sel
20
RO1 Level Sel
21
TO0 Level Sel
21
RO1 Level
22
TO0 Level
22
RO1 Level CmpSts
23
TO0 Level CmpSts
23
RO1 On Time
24
TO0 On Time
24
RO1 Off Time
25
TO0 Off Time
25
TO1 Sel
30
TO1 Level Sel
31
TO1 Level
32
TO1 Level CmpSts
33
TO1 On Time
34
TO1 Off Time
35
Motor PTC
ATEX Sts
41
Analog Inputs
Anlg In Type
45
Anlg In Sqrt
46
Anlg In Loss Sts
47
Anlg In0 Value
50
Anlg In0 Hi
51
Anlg In0 Lo
52
Anlg In0 LssActn
53
Anlg In0 Raw Val
54
Anlg In0 Filt Gn
55
Anlg In0 Filt BW
56
Analog Outpts
Anlg Out Type
70
Anlg Out Abs
71
Anlg Out0 Sel
75
Anlg Out0 Stpt
76
Anlg Out0 Data
77
Anlg Out0 DataHi
78
Anlg Out0 DataLo
79
Anlg Out0 Hi
80
Anlg Out0 Lo
81
Anlg Out0 Val
82
Predictive Main
PredMaint Sts
99
RO0 Load Type
100
RO0 Load Amps
101
RO0 TotalLife
102
RO0 ElapsedLife
103
RO0 RemainLife
104
RO0 LifeEvntLvl
105
RO0 LifeEvntActn
106
RO1 Load Type
110
RO1 Load Amps
111
RO1 TotalLife
112
RO1 ElapsedLife
113
RO1 RemainLife
114
RO1 LifeEvntLvl
115
RO1 LifeEvntActn
116
11-SERIES I/O
