118 Rockwell Automation Publication 750-PM001J-EN-P - October 2014
Chapter 3 Drive Port 0 Parameters
SPEED C
O
NTROL
Speed T
rim
602
606 Trim RefA AnlgHi
Trim RefB AnlgHi
Trim Reference A, B Analog High
Used only when an analog input is selected as a trim source according to P600 or P604.
Sets the amount of trim that corresponds to P51/61 [Anlg Inn Hi] on an I/O module or on
the main control (product dependent). This establishes scaling throughout the range. Units:
Default:
Min/Max:
Hz
RPM
P520 [Max Fwd Speed]
P521 [Max Rev Speed] / P520 [Max Fwd
Speed] RW Real
603
607 Trim RefA AnlgLo
Trim RefB AnlgLo
Trim Reference A, B Analog Low
Used only when an analog input is selected as a trim source according to P600/604 [Trim
Ref n Sel]. Sets the amount of trim that corresponds to P52/62 [Anlg Inn Lo] on an I/O
module or on the main control (product dependent). This establishes scaling throughout
the range. Units:
Default:
Min/Max:
Hz
RPM
0.00
P521 [Max Rev Speed] / P520 [Max Fwd
Speed] RW Real
608
612 TrmPct RefA Sel
TrmPct RefB Sel
Trim Percent Reference A, B Select
Selects a trim source (in %) for Speed Reference A or Speed Reference B, respectively. For
trim in Hz or RPM instead of %, use P600/604 [Trim Ref n Sel]. Default:
Min/Max:
P609 [TrmPct RefA Stpt]
P613 [TrmPct RefB Stpt]
0 / 159999 RW 32-bit
Integer
609
613 TrmPct RefA Stpt
TrmPct RefB Stpt
Trim Percent Reference A, B Setpoint
A digital value to be used a possible trim source for P608 or P612, respectively. Units:
Default:
Min/Max: %
0.000
–/+800.000 RW Real
610
614 TrmPct RefA AnHi
TrmPct RefB AnHi
Trim Percent Reference A, B Analog High
Used only when an analog input is selected as a percent trim source according to P608 or
P612. Sets the amount of trim that corresponds to P51/61 [Anlg Inn Hi] on an I/O
module or on the main control (product dependent). This establishes scaling throughout
the range. Units:
Default:
Min/Max: %
100.00
–/+800.00 RW Real
611
615 TrmPct RefA AnLo
TrmPct RefB AnLo
Trim Percent Reference A, B Analog Low
Used only when an analog input is selected as a percent trim source according to P608 or
P612. Sets the amount of trim that corresponds to P52/62 [Anlg Inn Lo] on an I/O
module or on the main control (product dependent). This establishes scaling throughout
the range. Units:
Default:
Min/Max: %
0.00
–/+800.00 RW Real
616 SpdTrimPrcRefSrc
Speed Trim Percent Reference Source
Displays the source of Motor Speed Reference Trim Percent, in the format SSPPPP, where
SS indicates the source port number other than Port 0 and PPPP indicates the source
parameter number. A value of zero indicates that a source has not been assigned. Default:
Min/Max: 0
0 / 159999 RO 32-bit
Integer
617 Spd Trim Source
Speed Trim Source
Displays the source of Motor Speed Reference Trim, in the format SSPPPP, where SS
indicates the source port number other than Port 0 and PPPP indicates the source
parameter number. A value of zero indicates that a source has not been assigned. Default:
Min/Max: 0
0 / 159999 RO 32-bit
Integer
Fi
le
Gro
u
p
No. Display Name
Full Name
Description Values
Read-W
ri
te
Da
ta
T
yp
e
