Embedded Feature and Option Module Parameters Chapter 5
11-S
eries I/O
D
igi
tal
O
u
tpu
ts
25 RO1 Off Time
Relay Output 1 Off Time – 11-Series I/O Module model 20-750-1132C-2R or 20-750-
1132D-2R is installed.
TO0 Off Time
Transistor Output 0 Off Time – 11-Series I/O Module model 20-750-1133C-1R2T is
installed.
Sets the “OFF Delay” time for the digital outputs. This is the time between the
disappearance of a condition and de-activation of the relay or transistor. Units:
Default:
Min/Max: Secs
0.0
0.0 / 600.0 RW Real
30 TO1 Sel
Transistor Output 1 Select
Selects the source that will energize the transistor output.
Any status parameter bit can be used as an output source. For example P935 [Drive
Status 1] Bit 7 “Faulted.”
Important: Only used by 11-Series I/O Module model 20-750-1133C-1R2T. Default:
Min/Max: 0 (Disabled)
0 / 159999.15 RW 32-bit
Integer
31 TO1 Level Sel
Transistor Output 1 Level Select
Selects the source of the level that will be compared.
Important: Only used by 11-Series I/O Module model 20-750-1133C-1R2T. Default:
Min/Max: 0 (Disabled)
0 / 159999.15 RW 32-bit
Integer
32 TO1 Level
Transistor Output 1 Level
Sets the level compare value.
Important: Only used by 11-Series I/O Module model 20-750-1133C-1R2T. Default:
Min/Max: 0.0
–/+1000000.0 RW Real
33 TO1 Level CmpSts
Transistor Output 1 Level Compare Status RO 16-bit
Integer
Status of the level compare, and a possible source for a transistor output. Transistor Output n Select must have this selected to energize the output. Can be used
without a physical output as status information only.
Bit 0 “Less Than” – Level source is less than the level value.
Bit 1 “Grt Than Equ” – Level source is greater than or equal to the level value.
Bit 2 “Abs Less Than” – Absolute value of the level source is less than the absolute value of the level value.
Bit 3 “AbsGrtThanEq” – Absolute value of the level source is greater than or equal to the absolute value of the level value.
Important: Only used by 11-Series I/O Module model 20-750-1133C-1R2T.
34 TO1 On Time
Transistor Output 1 On Time
Sets the “ON Delay” time for the digital outputs. This is the time between the occurrence
of a condition and activation of the transistor.
Important: Only used by 11-Series I/O Module model 20-750-1133C-1R2T. Units:
Default:
Min/Max: Secs
0.0
0.0 / 600.0 RW Real
35 TO1 Off Time
Transistor Output 1 Off Time
Sets the “OFF Delay” time for the digital outputs. This is the time between the
disappearance of a condition and de-activation of the transistor.
Important: Only used by 11-Series I/O Module model 20-750-1133C-1R2T. Units:
Default:
Min/Max: Secs
0.0
0.0 / 600.0 RW Real
Fi
le
Grou
p
No. Display Name
Full Name
Description Values
Re
ad
-W
ri
te
Da
ta
T
ype
Options
Res
er
ved
Res
er
ved
Res
er
ved
Res
er
ved
Res
er
ved
Res
er
ved
Res
er
ved
Res
er
ved
Res
er
ved
Res
er
ved
Res
er
ved
Res
er
ved
Ab
sG
rt
Th
an
Eq
Ab
s L
es
s T
ha
n
Gr
t Th
an
Eq
u
Le
ss
Th
an
Default 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
0 = Condition False
1 = Condition True
