Chapter 3
Drive Port 0 Parameters
Drive (Port 0) Applications
File
Fil
e
Gr
oup
No.
Display Name
Full Name
Description
Values
Re
ad
-Write
Da
ta
T
yp
e
APPLIC
AT
ION
S
Proces
s P
ID
1065
PID Cfg
PID Configuration
RW 16-bit
Integer
Main configuration of the Process PID controller.
Bit 0 “Preload Int” – Preload the PID integral term with PID Preload value.
Bit 1 “Ramp Ref” – Ramp PID Reference when first enabled.
Bit 2 “Zero Clamp” – Clamp PID output to zero when P1079 [PID Output Sel] is set to option 2 “Speed Trim” or 4 “Torque Trim.”
Bit 3 “Fdbk Sqrt” – Apply Square root function to the Feedback signal.
Bit 4 “Stop Mode” – When P1079 [PID Output Sel] is set to option 2 “Speed Trim,” PID remains active during stopping maneuver.
Bit 5 “Anti Windup” – Prevents PID integrator from getting too far ahead of frequency ramp.
Bit 6 “Percent Ref” – When P1079 [PID Output Sel] is set to option 2 “Speed Trim,” PID output is a percentage of the Speed Reference versus a percentage of P27
[Motor NP Hertz].
1066
PID Control
PID Control
RW 16-bit
Integer
Used for dynamically controlling the Process PID controller.
Bit 0 “PID Enable” – PID controller is enabled.
Bit 1 “PID Hold” – Hold PID integrator.
Bit 2 “PID Reset” – Reset PID integrator.
Bit 3 “PID InvError” – Invert PID error.
1067
PID Ref Sel
PID Reference Select
Selects the source for the PID Reference.
Default:
Min/Max:
1070
1 / 159999
RW 32-bit
Integer
1068
PID Ref AnlgHi
PID Reference Analog High
When an analog input is selected for PID Ref this sets high value of scaling.
Units:
Default:
Min/Max:
%
100.00
–/+100.00
RW Real
1069
PID Ref AnlgLo
PID Reference Analog Low
When an analog input is selected for PID Ref this sets low value of scaling.
Units:
Default:
Min/Max:
%
0.00
–/+100.00
RW Real
1070
PID Setpoint
PID Setpoint
Provides an internal fixed value for PID Ref when P1067 [PID Ref Sel] is set to this
parameter.
Units:
Default:
Min/Max:
%
0.00
–/+100.00
RW Real
1071
PID Ref Mult
PID Reference Multiplier
Sets the multiplying factor which is applied to the Reference source before the
Reference is used.
Units:
Default:
Min/Max:
%
100.00
–/+100.00
RW Real
Options
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Pe
rc
en
t R
ef
Anti W
indup
Stop
Mo
de
Fdbk Sqr
t
Ze
ro
Cl
am
p
Ra
mp Ref
Pr
el
oa
d I
nt
Default
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Bit
15 14 13 12 11 10 9
8
7
6
5
4
3
2
1
0
0 = Disabled
1 = Enabled
Options
Rese
rv
ed
Rese
rv
ed
Rese
rv
ed
Rese
rv
ed
Rese
rv
ed
Rese
rv
ed
Rese
rv
ed
Rese
rv
ed
Rese
rv
ed
Rese
rv
ed
Rese
rv
ed
Rese
rv
ed
PI
D I
nv
Err
or
PI
D R
ese
t
PID Hol
d
PI
D Ena
ble
Default
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
Bit
15 14 13 12 11 10 9
8
7
6
5
4
3
2
1
0
0 = Condition False
1 = Condition True
