Ctrl Bd Overtemp
10
0
Control Module Overtemperature
Factory Limit
61
Shear Pin 1
56
0
Overtorque Limit
64
Drive OverLoad
13
0
Converter Pre-charge Overload User
Limit
71
Port 1 Adapter
63
71
Product Specific
72
Port 2 Adapter
63
72
Product Specific
73
Port 3 Adapter
63
73
Product Specific
74
Port 4 Adapter
63
74
Product Specific
75
Port 5 Adapter
63
75
Product Specific
76
Port 6 Adapter
63
76
Product Specific
77
IR Volts Range
21
1
Motor Test Failure
78
FluxAmpsRef Rang
21
2
Motor Test Failure
79
Excessive Load
21
3
Motor Test Failure
80
AutoTune Aborted
21
4
Motor Test Failure
81
Port 1 DPI Loss
63
81
Product Specific
82
Port 2 DPI Loss
63
82
Product Specific
83
Port 3 DPI Loss
63
83
Product Specific
84
Port 4 DPI Loss
63
84
Product Specific
85
Port 5 DPI Loss
63
85
Product Specific
86
Port 6 DPI Loss
63
86
Product Specific
87
IXo VoltageRange
21
5
Motor Test Failure
91
Pri VelFdbk Loss
45
255
Feedback Data Loss Factory Limit
93
Hw Enable Check
63
93
Product Specific
94
Alt VelFdbk Loss
45
255
Feedback Data Loss Factory Limit
95
Aux VelFdbk Loss
45
255
Feedback Data Loss Factory Limit
96
PositionFdbkLoss
45
255
Feedback Data Loss Factory Limit
100
Parameter Chksum
3
0
Nonvolatile Memory Checksum Fault
104
Pwr Brd Checksum
15
1
Power Board
106
Incompat MCB-PB
15
3
Power Board
107
Replaced MCB-PB
22
1
Hardware Configuration
111
PwrBd Invalid ID
15
2
Power Board
112
PwrBd App MinVer
15
4
Power Board
113
Tracking DataErr
22
2
Hardware Configuration
117
PwrDn Data Chksm
17
16
Option Storage Checksum
124
App ID Changed
23
1
Firmware Change
125
Using Backup App
23
2
Firmware Change
134
Start On PowerUp
63
134
Product Specific
137
Ext Prchrg Err
23
2
Converter Pre-Charge Failure
138
Precharge Open
23
3
Converter Pre-Charge Failure
141
Autn Enc Angle
21
6
Motor Test Failure
142
Autn Spd Rstrct
21
7
Motor Test Failure
143
Autotune CurReg
21
8
Motor Test Failure
144
Autotune Inertia
21
9
Motor Test Failure
145
Autotune Travel
21
10
Motor Test Failure
PowerFlex 755 Drive
Integrated Motion on EtherNet/IP
Event No.
Fault Text
Code
Subcode
Fault Text
