Rockwell Automation Publication 750-PM001J-EN-P - October 2014 231
Port 10 and Port 11 Parameters Chapter 4
Fil
e
Gr
ou
p
No. Display Name
Full Name
Description Values
Re
ad
-Write
Da
ta T
ype
PREC
HARGE N
Meteri
ng
110
210
310 P1 DC Bus Volts
P2 DC Bus Volts
P3 DC Bus Volts
Precharge n DC Bus Voltage
Indicates the DC voltage on the inverter capacitor bank. This voltage is measured at a
point after the precharge resistors and contactor.
Units:
Default:
Min/Max: V DC
0.0
0.0 / 1200.0 RO Real
111
211
311 P1 Main DC Volts
P2 Main DC Volts
P3 Main DC Volts
Precharge n Main DC Voltage
Indicates the input DC voltage to the drive. This voltage is measured at the input to the
drive before the precharge resistors and contactor.
Units:
Default:
Min/Max: V DC
0.0
0.0 / 1200.0 RO Real
112
212
312 P1 240VSplyVolts
P2 240VSplyVolts
P3 240VSplyVolts
Precharge n 240 V Supply Voltage
Indicates the RMS output voltage of the 240V AC control transformer.
Units:
Default:
Min/Max: V AC
0.0
0.0 / 500.0 RO Real
122
222
322 P1 GateBoardTemp
P2 GateBoardTemp
P3 GateBoardTemp
Precharge n Gate Board Temperature
Gate board temperature for precharge n.
Units:
Default:
Min/Max: DegC
0.0
–/+200.0 RO Real
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
Fil
e
Gr
ou
p
No. Display Name
Full Name
Description Values
Re
ad
-Write
Da
ta
T
yp
e
PRECHARGE N
Pr
edi
cti
ve
Main
137
237
337 P1 PredMainReset
P2 PredMainReset
P3 PredMainReset
Precharge n Predictive Maintenance Reset
Allows a reset of the elapsed run time to zero for the cabinet fan for precharge n. After
the time has been reset, the value of this parameter returns to 0 “Ready.”
Default:
Options: 0 = “Ready”
0 = “Ready”
1 = “Cb Fan Life” RW Real
138
238
338 P1 CbFanElpsdLif
P2 CbFanElpsdLif
P3 CbFanElpsdLif
Precharge n Cabinet Fan Elapsed Life
The amount of time the cabinet fan for precharge n has been running. This value can be
reset using [Pn PredMainReset].
Units:
Default:
Min/Max: Hrs
0.000
0.000 / 2200000.000 RO Real
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
