Rockwell Automation Publication 750-PM001J-EN-P - October 2014 225
Port 10 and Port 11 Parameters Chapter 4
CO
N
VE
R
TE
R
N
Met
erin
g
125
225
325 C1 L12 Line Volt
C2 L12 Line Volt
C3 L12 Line Volt
Converter n Line 1 to Line 2 Line Voltage
The phase-to-phase RMS line voltage between L1 and L2 for converter n.
Units:
Default:
Min/Max: V AC
0.0
0.0 / 850.0 RO Real
126
226
326 C1 L23 Line Volt
C2 L23 Line Volt
C3 L23 Line Volt
Converter n Line 2 to Line 3 Line Voltage
The phase-to-phase RMS line voltage between L2 and L3 for converter n.
Units:
Default:
Min/Max: V AC
0.0
0.0 / 850.0 RO Real
127
227
327 C1 L31 Line Volt
C2 L31 Line Volt
C3 L31 Line Volt
Converter n Line 3 to Line 1 Line Voltage
The phase-to-phase RMS line voltage between L3 and L1 for converter n.
Units:
Default:
Min/Max: V AC
0.0
0.0 / 850.0 RO Real
Fi
le
Grou
p
No. Display Name
Full Name
Description Values
Re
ad
-W
ri
te
Da
ta
T
ype
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
