Rockwell Automation 21G PowerFlex 750-Series AC Drives Programming Manual User Manual
Page 222
222
Rockwell Automation Publication 750-PM001J-EN-P - October 2014
Chapter 4
Port 10 and Port 11 Parameters
Fil
e
Gr
ou
p
No.
Display Name
Full Name
Description
Values
Re
ad
-Write
Da
ta T
ype
CO
N
V
ER
TE
R
CO
M
M
O
N
Co
n
fi
gur
at
io
n
16
Gnd Cur Flt Lvl
Ground Current Fault Level
The converter system peak ground current fault threshold. The converter will fault if the
peak input ground current exceeds this threshold for five line cycles on any converter.
Units:
Default:
Min/Max:
Amps
600.0
0.0 / 3000.0
RW Real
755 (8+)
Fil
e
Gr
ou
p
No.
Display Name
Full Name
Description
Values
Re
ad
-Write
Da
ta
T
yp
e
CO
N
V
ER
TE
R C
O
M
M
O
N
Meterin
g
20
L1 Phase Curr
Line 1 Phase Current
The converter system AC line 1 (R) RMS input current. This is the sum of all line 1 (R)
phase currents from all online converters.
Units:
Default:
Min/Max:
Amps
0.0
0.0 / 15000.0
RO
Real
21
L2 Phase Curr
Line 2 Phase Current
The converter system AC line 2 (S) RMS input current. This is the sum of all line 2 (S)
phase currents from all online converters.
Units:
Default:
Min/Max:
Amps
0.0
0.0 / 15000.0
RO
Real
22
L3 Phase Curr
Line 3 Phase Current
The converter system AC line 3 (T) RMS input current. This is the sum of all line 3 (T)
phase currents from all online converters.
Units:
Default:
Min/Max:
Amps
0.0
0.0 / 15000.0
RO
Real
23
Heatsink Temp
Heatsink Temperature
The converter system heatsink temperature. This is the maximum heatsink temperature
from all online converters.
Units:
Default:
Min/Max:
DegC
0.0
–/+200.0
RO
Real
24
SCR Temp
SCR Temperature
The converter system SCR temperature. This is the maximum SCR temperature from all
online converters.
Units:
Default:
Min/Max:
DegC
0.0
–/+200.0
RO
Real
25
Gate Board Temp
Gate Board Temperature
The converter system gate board temperature. This is the maximum gate board
temperature from all online converters
Units:
Default:
Min/Max:
DegC
0.0
–/+200.0
RO
Real
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
755 (8+)
Fil
e
Gr
oup
No.
Display Name
Full Name
Description
Values
Re
ad
-Write
Da
ta
T
yp
e
CO
N
V
ER
TE
R
C
O
M
M
O
N
Te
st
po
in
ts
30
32
Testpoint Sel 1
Testpoint Sel 2
Testpoint Selection 1, 2
Selects a source for [Testpoint Val n]. Used by the factory, typically for diagnostic
purposes.
Default:
Min/Max:
0
0 / 65535
RW 32-bit
Integer
31
33
Testpoint Val 1
Testpoint Val 2
Testpoint Value 1, 2
Displays data selected by [Testpoint Sel n].
Default:
Min/Max:
0.000000
–/+220000000.000000
RO
Real
755 (8+)
755 (8+)
755 (8+)
755 (8+)
