Rockwell Automation 21G PowerFlex 750-Series AC Drives Programming Manual User Manual
Page 138
138
Rockwell Automation Publication 750-PM001J-EN-P - October 2014
Chapter 3
Drive Port 0 Parameters
Fil
e
Gr
ou
p
No.
Display Name
Full Name
Description
Values
Re
ad
-Write
Da
ta T
ype
POSITION
C
O
NTR
O
L
Po
si
ti
on W
at
ch
745
748
PsnWatch1 Select
PsnWatch2 Select
Position Watch n Select
Selects a position feedback source that is compared to the position watch detect-input
P746 [PsnWatch1 DtctIn], P749 [PsnWatch2 DtctIn].
Default:
Min/Max:
847
1 / 159999
RW 32-bit
Integer
746
749
PsnWatch1 DtctIn
PsnWatch2 DtctIn
Position Watch n Detect Input
Provides position feedback source for the position watch function. The position watch
function is enabled and configured by the position control configuration P721 [Position
Control]. The position watch function compares this value to the position watch set
point P747 [PsnWatch1 Stpt], P750 [PsnWatch2 Stpt] when this parameter P746, P749
is selected by the position watch select P745 [PsnWatch1 Select], P748 [PsnWatch2
Select]. The position detect bit P724 [Psn Reg Status] Bit 9 “PsnW1Detect”, Bit 10
“PsnW2Detect” is set when the appropriate condition is satisfied.
Default:
Min/Max:
0
–2147483648 / 2147483647
RW 32-bit
Integer
747
750
PsnWatch1 Stpt
PsnWatch2 Stpt
Position Watch n Setpoint
Provides set point for the position watch function. The position watch function is
enabled and configured by P721 [Position Control]. The position watch function
compares this value to the position feedback source selected by the position watch
select P745 [PsnWatch1 Select], P748 [PsnWatch2 Select]. The position detect bit P724
[Psn Reg Status] Bit 9 “PsnW1Detect”, Bit 10 “PsnW2Detect” is set when the appropriate
condition is satisfied.
Default:
Min/Max:
0
–2147483648 / 2147483647
RW 32-bit
Integer
755
755
755
755
755
755
Fil
e
Gr
ou
p
No.
Display Name
Full Name
Description
Values
Re
ad
-Write
Da
ta
T
yp
e
POSI
TI
ON C
O
N
TR
O
L
Inte
rpol
ator
755
Interp Control
Interpolator Control
Reserved for future use.
Default:
Options:
0
1 / 2147483647
RW 32-bit
Integer
756
Interp Psn Input
Interpolator Position Input
Input value to the Command Position fine interpolator.
Default:
Min/Max:
0
–2147483648 / 2147483647
RW 32-bit
Integer
757
Interp Vel Input
Interpolator Velocity Input
Input value to the Command Velocity fine interpolator.
Units:
Default:
Min/Max:
Hz
RPM
0.00
–/+1000000.00
RW Real
758
Interp Trq Input
Interpolator Torque Input
Input value to the Command Torque fine interpolator.
Default:
Min/Max:
0.00
–/+1000000.00
RW Real
759
Interp Psn Out
Interpolator Position Output
Output value from the Command Position fine interpolator.
Default:
Min/Max:
0
–2147483648 / 2147483647
RW 32-bit
Integer
760
Interp Vel Out
Interpolator Velocity Output
Output value from the Command Velocity fine interpolator. When no Command Velocity
signal is present when performing position control, this signal can be derived by scaling
the Differential Position output value of the Command Position fine interpolator.
Units:
Default:
Min/Max:
Hz
RPM
0.00
–/+1000000.00
RW Real
761
Interp Trq Out
Interpolator Torque Output
Command torque output from fine interpolator (if active) into torque input summing
junction when configured for toque control.
Default:
Min/Max:
0.00
–/+1000000.00
RW Real
