Start Up Chapter 1
Start-Up Menu The Human Interface Module (HIM) displays the General Start-Up menu by
default upon initial power up of the drive. To navigate to the Start-Up menu after
the initial power up of the drive, press the (Folders) key.
General Startup
Start-Up Main Menu
Complete these steps in order:
Motor Control
Motor Data
Feedback
Limits
Tests
Ref, Ramp, Stop
I/O
Done
Motor Control Motor Data Feedback Limits Tests Reference I/O Done
Motor Ctrl Motor Data Feedback
Config
Limits Tests Ref, Ramp,
Stop
I/O Return to
Main Menu
Motor Ctrl
Return
Motor Data
Return
Fdbk Cnfg
Return
Limits
Return
Tests
Return
Ref, Ramp,
Stop
Return
I/O
Return
Return to
Main Menu
IMPORTANT If a start up routine is initiated, but must be terminated before the routine is
completed, be sure to press the Abort soft key to completely exit the routine.
