15 Parameter reference
15.2 Parameter list | C00951
766
Lenze · 8400 StateLine · Reference manual · DMS 12.0 EN · 06/2014 · TD05/TD14
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00951
C00952
C00953
C00965
C00966
Parameter | Name:
C00951 | L_Interpolator_1: No. of interpolation steps
Data type: UNSIGNED_16
Index: 23624
d
= 5C48
h
From version 04.00.00
The L_Interpolator_1 FB: No. of interpolation steps
Setting range (min. value | unit | max. value) Lenze setting
0 65535 1
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00952 | L_Interpolator_1: Limit value - error cycles
Data type: UNSIGNED_16
Index: 23623
d
= 5C47
h
From version 04.00.00
The L_Interpolator_1 FB: Limit value for missing data telegrams
Setting range (min. value | unit | max. value) Lenze setting
0 65535 5
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00953 | L_Interpolator_1: Speed-up
Data type: UNSIGNED_8
Index: 23622
d
= 5C46
h
From version 04.00.00
FB L_Interpolator_1 : Limitation of the number of correction increments per cycle (speed-up)
Setting range
(min. value | unit | max. value)
Lenze setting
0 100 0
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00965 | Max. motor speed
Data type: UNSIGNED_16
Index: 23610
d
= 5C3A
h
From version 10.00.00
When the drive reaches the motor speed set here:
• The "Fault" error response takes place, i.e. the motor is shut down immediately.
• The error message " oS2: Max. motor speed reached " is entered into the logbook.
Setting range (min. value | unit | max. value) Lenze setting
50 rpm 65000 60000 rpm
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00966 | VFC: Time const. slip comp.
Data type: UNSIGNED_16
Index: 23609
d
= 5C39
h
From version 02.00.00
Filter time constant of the slip compensation for V/f characteristic control ( VFCplus )
• The time constant of slip compensation serves to specify the dynamics of slip compensation for V/f characteristic
control without feedback.
• The lower the selected time constant, the higher the dynamic performance of the slip compensation.
Setting range (min. value | unit | max. value) Lenze setting
1 ms 6000 100 ms
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
