15
Parameter reference
15.2
Parameter list | C00246
654
Lenze · 8400 StateLine · Reference manual · DMS 12.0 EN · 06/2014 · TD05/TD14
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00246
C00247
C00249
C00254
C00265
C00270
Parameter | Name:
C00246 | L_PCTRL_1: nAct_a internal
Data type: INTEGER_16
Index: 24329
d
= 5F09
h
From version 04.00.00
FB
: Display of the internal actual value
Display range
(min. value | unit | max. value)
-199.99
%
199.99
Read access Write access CINH PLC STOP No transfer COM MOT
Scaling factor: 100
Parameter | Name:
C00247 | L_PCTRL_1: Window setpoint reached
Data type: INTEGER_16
Index: 24328
d
= 5F08
h
From version 06.00.00
FB
: Window for comparison operation "actual value = setpoint"
Setting range
(min. value | unit | max. value)
Lenze setting
0.00
%
100.00 2.00 %
Read access Write access CINH PLC STOP No transfer COM MOT
Scaling factor: 100
Parameter | Name:
C00249 | L_PT1_1: Time constant
Data type: UNSIGNED_16
Index: 24326
d
= 5F06
h
FB
: Time constant Tn
Setting range
(min. value | unit | max. value)
Lenze setting
0
ms
5000 2000 ms
Read access Write access CINH PLC STOP No transfer COM MOT
Scaling factor: 1
Parameter | Name:
C00254 | Service parameter
Data type: UNSIGNED_16
Index: 24321
d
= 5F01
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00265 | SLVC: Tn torque controller
Data type: UNSIGNED_8
Index: 24310
d
= 5EF6
h
This code is for device-internal use only and must not be written to by the user!
Parameter | Name:
C00270 | SC: Freq. current setpoint filter
Data type: UNSIGNED_16
Index: 24305
d
= 5EF1
h
Frequency to be inhibited by the current setpoint filter at sensorless control for synchronous motors (
Setting range
(min. value | unit | max. value)
Lenze setting
40.0
Hz
1000.0 200.0 Hz
Read access Write access CINH PLC STOP No transfer COM MOT
Scaling factor: 10
