15 Parameter reference
15.2 Parameter list | C00620
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00620/16 0: Not connected LS_DisFree_a : nDis3_a
Display of analog signal 3
C00620/17 0: Not connected LS_DisFree_a : nDis4_a
Display of analog signal 4
C00620/18 0: Not connected LS_DisFree : wDis1
Display of 16-bit signal 1
C00620/19 0: Not connected LS_DisFree : wDis2
Display of 16-bit signal 2
C00620/20 0: Not connected LS_DisFree : wDis3
Display of 16-bit signal 3
C00620/21 0: Not connected LS_DisFree : wDis4
Display of 16-bit signal 4
C00620/22 0: Not connected LP_MciOut : wState
MCI output: Status word
C00620/23 0: Not connected LP_MciOut : wOut2
MCI output: Data word 2
C00620/24 0: Not connected LP_MciOut : wOut3
MCI output: Data word 3
C00620/25 0: Not connected LP_MciOut : wOut4
MCI output: Data word 4
C00620/26 0: Not connected LP_MciOut : wOut5
MCI output: Data word 5
C00620/27 0: Not connected LP_MciOut : wOut6
MCI output: Data word 6
C00620/28 0: Not connected LP_MciOut : wOut7
MCI output: Data word 7
C00620/29 0: Not connected LP_MciOut : wOut8
MCI output: Data word 8
C00620/30 0: Not connected LP_MciOut : wOut9
MCI output: Data word 9
C00620/31 0: Not connected LP_MciOut : wOut10
MCI output: Data word 10
C00620/32 0: Not connected LP_MciOut : wOut11
MCI output: Data word 11
C00620/33 0: Not connected LP_MciOut : wOut12
MCI output: Data word 12
C00620/34 0: Not connected LP_MciOut : wOut13
MCI output: Data word 13
C00620/35 0: Not connected LP_MciOut : wOut14
MCI output: Data word 14
C00620/36 0: Not connected LP_MciOut : wOut15
MCI output: Data word 15
C00620/37 0: Not connected LP_MciOut : wOut16
MCI output: Data word 16
C00620/49 0: Not connected LS_ParReadWrite_1 : wParIndex
Read/write request 1: Code
C00620/50 0: Not connected LS_ParReadWrite_1 : wParSubindex
Read/write request 1: Subcode
C00620/51 0: Not connected LS_ParReadWrite_1 : wInHWord
Read/write request 1: Value (high word)
Parameter | Name:
C00620 | System connection list: 16-bit
Data type: UNSIGNED_16
Index: 23955
d
= 5D93
h
