15 Parameter reference
15.2 Parameter list | C00834
752
Lenze · 8400 StateLine · Reference manual · DMS 12.0 EN · 06/2014 · TD05/TD14
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
C00834
C00833/117 L_JogCtrlExtension : bStop1
C00833/118 L_JogCtrlExtension : bbSlowDown2
C00833/119 L_JogCtrlExtension : bStop2
C00833/120 L_JogCtrlExtension : bSlowDown3
C00833/121 L_JogCtrlExtension : bStop3
C00833/122 L_PCTRL_1 : bISet
C00833/123 L_Interpolator_1 : bSpeedAct0
C00833/124 L_Or_4 : bIn1
C00833/125 L_Or_4 : bIn2
C00833/126 L_Or_4 : bIn3
C00833/127 L_DigitalLogic_3 : bIn1
C00833/128 L_DigitalLogic_3 : bIn2
C00833/129 L_DigitalLogic_3 : bIn3
C00833/130 MCTRL : bBrakeChopperOn
C00833/131 MCTRL : bVfcEcoDisable
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
Parameter | Name:
C00833 | Binary inputs
Data type: UNSIGNED_8
Index: 23742
d
= 5CBE
h
Parameter | Name:
C00834 | 32-bit inputs [incr]
Data type: INTEGER_32
Index: 23741
d
= 5CBD
h
From version 03.00.00
Display in [increments] of 32 bit input values of various blocks
• Non-listed subcodes are "reserved".
Display range (min. value | unit | max. value)
-2147483647 Incr. 2147483647
Subcodes Info
C00834/1 MCK: dnPosSetValue_p
C00834/2 MCK: dnMotorRefOffset_p
C00834/3 MCK: dnDeltaPos_p
C00834/4 MCTRL : dnDeltaPos_p
C00834/5 MCTRL : dnPosSetValue_p
C00834/6 MCTRL : dnMotorRefOffset_p
C00834/7 MCK: dnProfilePosition_p
C00834/8 L_Interpolator_1 : dnPhiIn_p
 Read access  Write access  CINH  PLC STOP  No transfer  COM  MOT Scaling factor: 1
