Allied Telesis AT-UWC Series - Manual (Page 77)

Chapter 2: System
77
Supported MIBs
From the Supported MIBs page, you can view a list of MIB’s that the
WLAN Controller supports.
To view a list of supported MIB’s, do the following:
1. From the Navigation pane, go to System > SNMP > Supported MIBs.
The Supported MIBs page is displayed as shown in Figure 45.
Figure 45. SNMP Supported MIBs Page
2. Observe the following fields in Table 15.
.
3. If you want to view the most current information, click Refresh.
Table 15. SNMP Supported MIBs
Field Description
Name Displays the RFC number and MIB module name.
Description Displays the RFC title or description of the MIB
module.
