Chapter 5: Wireless LAN
265
Viewing the
Detailed Statistics
of Association
To view the detailed statistics of the traffic between the access point and
AP clients, do the following:
1. From the Navigation pane, go to WLAN > Status/Statistics >
Associated Client and click the Association Detail Statistics tab.
The Association Detail Statistics page is displayed.
2. Observe the fields described in Table 106.
3. If you want to refresh the display, click Refresh.
Table 106. Association Detail Statistics
Field Description
Packets Received Displays the number of packets that are received
from the client.
Bytes Received Displays the data size in bytes that are received
from the client.
Packets
Transmitted Displays the number of packets that are
transmitted to the client.
Bytes Transmitted Displays the data size in bytes that are transmitted
to the client.
Packets Receive
Dropped Displays the number of packets that are received
from the client, but dropped.
Bytes Received
Dropped Displays the data size in bytes that are received
from the client, but dropped.
Packets Transmit
Dropped Displays the number of packets that are
transmitted to the client, but dropped.
Bytes Transmit
Dropped Displays the data size in bytes that are transmitted
to the client, but dropped.
Fragments
Received Displays the number of fragments of the packets
that are received from the client.
Fragments
Transmitted Displays the number of fragments of the packets
that are transmitted to the client.
Transmit Retires Displays the number of times that traffic is
transmitted successfully to the client after the retry.
Transmit Retries
Failed Displays the number of times that traffic failed to
be transmitted to the client after the retry.
Duplicate Received Displays the number of duplicated packets that are
received from the client.
