AT-UWC WLAN Controller Web GUI User’s Guide
250
Figure 130. Managed Access Point Radio Statistics Page
2. Select the MAC address of the access point that you want to view the
radio information.
3. Select the radio band: 802.11b/g/n or 802.11a/n.
The radio information about the selected access point is displayed.
4. Observe the fields described in Table 94.
Table 94. Managed Access Point Radio Statistics
Field Description
WLAN Packets
Received Displays the number of packets that the access
point has received from the wireless network.
WLAN Packets
Transmitted Displays the number of packets that the access
point has transmitted to the wireless network.
WLAN Packets
Receive Dropped Displays the number of packets that the access
point has received from the wireless network, but
discarded.
WLAN Packets
Transmitted
Dropped Displays the number of packets that the access
point has transmitted to the wireless network, but
discarded.
Fragments
Received Displays the number of MPDU frames that the
access point received. The Type of MPDU frame
must be data or management.
