Chapter 3: Switching
133
VLAN Port Summary
From the VLAN Port Summary page, you can view the port setting.
To view the port setting, do the following:
1. From the Navigation pane, go to Switching> VLAN > VLAN Port
Summary.
The VLAN Port Summary page is displayed as shown in Figure 76.
Figure 76. VLAN Port Summary Page
2. Observed the fields described in Table 37.
Table 37. VLAN Port Summary
Field Description
Interface Displays the port interface.
Port VLAN ID
Configured Indicates the VLAN ID that the port applies to
untagged frames and frames with a priority tag.
Acceptable
Frame Types Indicates one of the following options:
 Admit ALL - The port accepts any frame
types. It forwards tagged frames as defined
in IEEE802.1Q. This is the default setting.
 AddmitTaggedOnly - The port accepts only
tagged frames and forwards them as
defined in IEEE 802.1Q.
 AddmitUntaggedOnly - The port discards
tagged frames.
