Allied Telesis AT-UWC Series - Manual (Page 252)

AT-UWC WLAN Controller Web GUI User’s Guide
252
5. If you want to refresh the display, click Refresh.
Viewing the
Statistics of VAP
To view the VAP statistics about the managed access points, do the
following:
1. From the Navigation pane, go to WLAN > Status/Statistics > Managed
AP, click the Statistics tab, then click the VAP subtab.
The Managed Access Point VAP Statistics page is displayed as shown
in Figure 131.
Figure 131. Managed Access Point VAP Statistics Page
2. Select the MAC address of the access point that have information
about the VAP.
3. Select the radio band: 802.11b/g/n or 802.11a/n.
4. Select the VAP from the select list.
The VAP information is displayed.
RTS Failure
Count Displays the number of CTS frames that the access
point did not receive as a response to RTS frames.
FCS Error Count Displays the number of FCS errors from the MPDU
frames that the access point received.
WEP
Undecryptable
Count Displays the number of frames that are not required
to be encrypted or discarded because the receiving
device has no privacy option.
Table 94. Managed Access Point Radio Statistics (Continued)
Field Description
