AT-UWC WLAN Controller Web GUI User’s Guide
282
Viewing WIDS
AP Rogue
Classification
To view the WIDS AP Rogue Classification, do the following:
1. From the Navigation pane, go to WLAN > Intrusion Detection >
Rogue/RF Scan.
The Access Point RF Scan Status page is displayed as shown in
Figure 139 on page 276.
2. Click a MAC address from the Access Point RF Scan Status.
The Access Point RF Scan Status Detail page is displayed as shown in
Figure 140 on page 278.
3. Click the WIDS AP Rogue Classification tab.
The WIDS AP Rogue Classification page is displayed as shown in
Figure 142.
Figure 142. WIDS AP Rogue Classification Page
4. Observe the fields described in Table 117.
Table 117. WIDS AP Rogue Classification
Field Description
Test Description Displays the test description.
Condition
Detected Displays the result of the test: True or False.
Reporting MAC
Address Displays the MAC address of the managed access
point.
