AT-UWC WLAN Controller Web GUI User’s Guide
246
3. If you want to refresh the display, click Refresh.
Viewing the
Detailed Statistics
of Managed
Access Point s
To view the detailed statistics about the managed access points, do the
following:
1. From the Navigation pane, go to WLAN > Status/Statistics > Managed
AP, click the Statistics tab, then click the Detail subtab.
The Managed Access Point Detail Statistics page is displayed as
shown in Figure 129.
Figure 129. Managed Access Point Detail Statistics Page
2. Select the MAC address of the access point that you want to view the
detail information.
3. Observe the fields described in Table 93.
Packets
Transmitted Displays the number of packets that the access
point has transmitted to the Ethernet.
Bytes
Transmitted Displays the data size in bytes that the access
point has transmitted to the Ethernet.
Table 92. Managed Access Point Ethernet Statistics (Continued)
Field Description
Table 93. Managed Access Point Detail Statistics
Field Description
WLAN Packets
Received Displays the number of packets that the access
point has received from the wireless network.
