Allied Telesis AT-UWC Series - Manual (Page 199)

Chapter 5: Wireless LAN
199
The Valid Access Point Summary page is displayed as shown in
Figure 105.
Figure 105. Valid Access Point Summary Page
2. Observe the fields described in Table 69.
3. Click Refresh as needed.
Adding an Access
Point
To add an access point to the valid AP list, do the following:
1. From the Navigation pane, go to WLAN > Basic Setup and click the
Valid AP tab.
Table 69. Valid Access Point Summary
Field Description
MAC address Displays the MAC address of an access point on the
valid AP list on the WLAN Controller.
Click the MAC address, Figure 106 on page 200 is
displayed.
Location Displays the location information of the access point.
AP Mode Displays the AP mode of the access point. The options
are:
 Managed - Managed by the WLAN Controller
 Standalone - Managed independently
 Rogue - Classified as a threat by WIDS
Profile Displays the AP profile assigned to the access point.
Click the profile, Figure 162 on page 328 is displayed.
