AT-UWC WLAN Controller Web GUI User’s Guide
110
3. If you want to display the most current information, click Refresh.
Adding a Static
Entry
To add a static entry do the following:
1. From the Navigation pane, go to System > System > DNS >
HostName IP Mapping Summary.
The DNS HostName Mapping Summary page is displayed as shown in
Figure 63 on page 109.
2. Click Add Static Entry.
The DNS HostName IP Mapping Configuration page is displays as
shown in Figure 64.
Figure 64. DNS HostName IP Mapping Configuration Page
3. Specify the following fields described in Table 28.
Elapsed Displays the time duration in seconds that the entry
has stayed on the list.
Type Displays the type of the entry.
Address Displays the IP address of the host.
Remove Dynamic Check the checkbox to remove the host.
Table 27. DNS HostName IP Mapping Summary (Continued)
Field Description
Table 28. DNS HostName IP Mapping Configuration
Field Description
Host Name Specify the name of the host.
