Chapter 4: Security
169
4. If you want to view the most current information, click Refresh.
Client Statistics
To view the statistics of connected AP clients, do the following:
1. From the Navigation pane, go to Security > Captive Portal > Client
Connection Status.
The Client Summary page is displayed.
2. Click the Client Statistics tab.
The Client Statistics page is displayed.
3. Observe the fields described in Table 55.
4. If you want to view the most current information, click Refresh.
Interface - Client
Status
To view the information about the interface of AP clients, do the following:
1. From the Navigation pane, go to Security > Captive Portal > Client
Connection Status.
The Client Summary page is displayed.
2. Click the Interface - Client Status tab.
The Interface - Client Status page is displayed.
Controller IP
Address Displays the IP address of the WLAN Controller that
authenticated the AP client. When clustering is
supported, the IP address of the peer controller may
be shown.
Table 54. Client Detail (Continued)
Field Description
Table 55. Client Statistics
Field Description
Bytes
Transmitted Displays the total size of data in bytes that are sent to
the AP client.
Bytes Received Displays the total size of data in bytes that are
received from the AP client.
Packets
Transmitted Displays the number of the packets that are sent to
the AP client.
Packets
Received Displays the number of the packets that are received
from the AP client.
