Chapter 5: Wireless LAN
237
Figure 122. Managed Access Point Radio Status Detail Page
2. Select the MAC address of the access point that you want to view the
radio information.
3. Select the radio band: 802.11b/g/n or 802.11a/n.
The radio information about the selected access point is displayed.
4. Observe the fields described in Table 86.
Table 86. Managed Access Point Radio Status Detail
Field Description
Supported
Channels Displays a list of supported channels. The
supported channels depend upon the country code,
access point hardware type, and selected channel
restriction.
Channel Displays the channel that is currently active.
Channel
bandwidth Displays the channel bandwidth: 20MHz or 40MHz.
Fixed Channel
Indicator Displays whether the channel is manually assigned
or not. To fix the channel, see “WLAN Basic Setup
> Valid AP” on page 198.
