AT-UWC WLAN Controller Web GUI User’s Guide
264
3. If you want to disconnect an AP client, check the checkbox next to the
MAC address of the AP client.
4. Click the following buttons as needed:
 Disassociate — Disconnect the selected AP client from the
access point.
 Refresh — Refreshes the display on this page.
Viewing the
Summary
Statistics of
Association
To view the statistics of the traffic between the access point and AP
clients, do the following:
1. From the Navigation pane, go to WLAN > Status/Statistics >
Associated Client and click the Association Summary Statistics tab.
The Association Summary Statistics page is displayed.
2. Observe the fields described in Table 105.
3. If you want to refresh the display, click Refresh.
Table 104. Associated Client Controller Status
Field Description
Controller IP
Address Displays the IP address of the WLAN Controller
that manges the access point, which the AP client
is associated with.
Client MAC
Address Displays the MAC address of the AP client.
Table 105. Association Summary Statistics
Field Description
MAC Address Displays the MAC address of the client station.
Packets Received Displays the number of packets that are received
from the client.
Bytes Received Displays the data size in bytes that are received
from the client.
Packets
Transmitted Displays the number of packets that are
transmitted to the client.
Bytes Transmitted Displays the data size in bytes that are transmitted
to the client.
