Chapter 2: System
45
Network Connectivity Configuration
From the Network Connectivity Configuration page, you can view and
modify the network interface properties.
To view and modify the network interface properties, do the following:
1. From the Navigation pane, go to System > Configuration > Network
Connectivity Configuration.
The Network Connectivity Configuration page is displayed as shown in
Figure 29.
Figure 29. Network Connectivity Configuration Page
2. Observe or modify the values in the fields described in Table 3.
Table 3. Network Connectivity Configuration
Field Description
Interface Status Displays the status of the interface on the WLAN
Controller.
IP Address Displays the IP address of the WLAN Controller.
The default value is 192.168.1.1.
Subnet Mask Displays the subnet mask of the WLAN Controller.
The default value is 255.255.255.0.
Default Gateway Displays the default gateway to the WLAN
Controller. By default, no value is assigned.
