Chapter 5: Wireless LAN
229
3. If you want to refresh the display, click Refresh.
Viewing
Configuration
Received
To view information about the configuration that the WLAN Controller
received from another peer controller, do the following:
1. From the Navigation pane, go to WLAN > Status/Statistics and click
the Configuration Received tab.
The Peer Controller Configuration Received Status page is displayed
as shown in Figure 119 on page 230.
Total Number of
Configured
Entries Displays the number of IP addresses that are
currently registered in the IP List.
Total Number of
Polled Entries Displays the number of IP addresses in the IP List
that the WLAN Controller sent discovery packets
to.
Total Number of
Non-Polled
Entries Displays the number of IP addresses in the IP List
that the WLAN Controller has not sent discovery
packets to.
Total Number of
Discovered
Entires Displays the number of IP addresses in the IP List
that the WLAN Controller successfully discovered
and authenticated or validated by polling.
Total Number of
Discovered-
Failed Entires Displays the number of IP addresses in the IP List
that the WLAN Controller failed to discover,
authenticate, or validate by polling.
IP Address Displays the IP address in the IP List.
Status Displays the status of the IP address. The options
are:
 Not Polled
 Polled
 Discovered
 Discovered Failed
Table 82. Wireless Discovery Status (Continued)
Field Description
