AT-UWC WLAN Controller Web GUI User’s Guide
162
3. If you want to view the most current information, click Refresh.
Viewing the
Activity Status
per CP Profile
To view the information about each CP profile, do the following:
1. From the Navigation pane, go to Security > Captive Portal > CP
Status.
The CP Global Status page is displayed as shown in Figure 89 on
page 161.
2. Click CP Activation and Activity Status tab.
The CP Activation and Activity Status page is displayed as shown in
Figure 90.
Figure 90. CP Activation and Activity Status Page
3. Select a CP profile from the select list.
System
Supported Users Displays the number of authenticated users that the
system supports.
CP IP Address Displays the IP address of Captive Portal.
Supported
Captive Portals Displays the number of CP profiles that the system
supports.
Configured
Captive Portals Displays the number of CP profiles that are defined
to the WLAN Controller.
Active Captive
Portals Displays the number of active CP instances.
Authenticated
Users Displays the number of users that are currently
authenticated in all the CP instances.
Table 49. CP Global Status (Continued)
Field Description
