Allied Telesis AT-UWC Series - Manual (Page 142)

AT-UWC WLAN Controller Web GUI User’s Guide
142
Figure 80. CP Configuration Page
3. Specify the fields described in Table 40.
Table 40. CP Configuration
Field Description
Enable Captive
Portal Check the checkbox to enable the CP profile.
Configuration
Name Specify the name of the CP profile.
Protocol Mode Select the protocol mode: HTTP or HTTPS.
Verification Mode Select the verification type of the CP profile. The
options are:
 Guest - No verification is implemented.
 Local - Verification is implemented on the
specified local users. See...
 RADIUS server - Verification is implemented
by the RADIUS server.
Mode Check the checkbox to allow a user of the AP client to
cancel verification. When the checkbox is unchecked,
the AP client is required for authentication until
Captive Portal cancels the authentication.
