AT-UWC WLAN Controller Web GUI User’s Guide
130
VLAN Status
From the VLAN Status page, you can view the information about VLAN’s
on the WLAN Controller.
To view the information about VLAN’s, do the following:
1. From the Navigation pane, click Switching > VLAN > Status.
The VLAN Status page is displayed as shown in Figure 74.
Figure 74. VLAN Status Page
2. Observe the fields described in Table 35.
3. If you want to view the most current information, click Refresh.
Table 35. VLAN Status
Field Description
VLAN ID Displays the ID of the VLAN.
VLAN Name Displays the name of the VLAN. The VLAN ID 1 is
always “default.”
VLAN Type Displays the following VLAN types:
 Default - Indicates that the VLAN is default
VLAN, which is the VLAN ID 1.
 Static - Indicates the VLAN is manually created.
