Chapter 5: Wireless LAN
273
2. Observe the fields described in Table 112.
3. If you want to refresh the display, click Refresh.
Viewing WDS
Link Statistics
To view the link statistics in the WDS group, do the following:
1. From the Navigation pane, go to WLAN > Status/Statistics > WDS
Managed APs and click the WDS Link Statistics tab.
The WDS Link Statistics page is displayed as shown in Figure 138 on
page 274.
Table 112. WDS Link Status
Field Description
WDS Group Id Displays the unique WDS group ID.
Source AP MAC
Address Displays the MAC address of the source access
point of the WDS group.
Source AP Radio Displays the radio band of the source access point.
The options are:
 1 - 2.4GHz
 2 - 5GHz
Destination AP
MAC Address Displays the MAC address of the destination
access point of the WDS group.
Destination AP
Radio Displays the radio band of the destination access
point. The options are:
 1 - 2.4GHz
 2 - 5GHz
Source End-
Point Detected Displays whether the destination access point
detects the source access point or not.
Destination End-
Point Detested Displays whether the source access point detects
the destination access point or not.
Aggregation
Mode Not Supported.
