AT-UWC WLAN Controller Web GUI User’s Guide
210
RF Management > Manual Channel Plan
From the RF Management > Manual Channel Plan page, you can start the
channel plan algorithm manually and apply the suggested new channel to
the access points.
Note
The channel plan algorithm only suggests a new channel. You must
click the Apply button to apply the new channel.
To start the channel plan algorithm and apply the change, do the following:
1. From the Navigation pane, go to WLAN > AP Management > RF
Management and click the Manual Channel Plan tab.
The Manual Channel Plan page is displayed as shown in Figure 111.
Figure 111. Manual Channel Plan Page
2. Select one of the following channel plan to run the algorithm:
 5 GHz (802.11 a/n)
 2.4 GHz (802.11 b/g/n)
3. Click Start.
4. Observe the status and suggested channel plans described in
Table 74 on page 211.
