AT-UWC WLAN Controller Web GUI User’s Guide
222
Cluster Controller Displays whether the WLAN Controller is the
cluster controller or not.
The cluster controller is a root controller in a peer
group setting. WLAN Controllers under the peer
group report information of all the managed access
points and their AP clients as well as the results of
RF scans to the cluster controller.
Cluster Controller
IP Address Displays the IP address of the cluster controller in
the peer group.
Total Access Points Displays the total number of the following access
points:
 Managed Access Points
 Connection Failed Access Points
 Discovered Access Points.
Managed Access
Points Displays the number of access points that are
successfully authenticated and actively connected
to the WLAN Controller.
Discovered Access
Points Displays the number of access points that are
discovered or authenticated, but not configured
completely.
Connection Failed
Access Points Displays the number of access points that were
authenticated before, but are not currently
connected to the WLAN Controller.
Maximum Managed
APs in Peer Group Displays the maximum number of access points
that the peer group manages.
Rogue Access
Points Displays the number of rogue access points that
the WLAN Controller currently classifies as.
Standalone Access
Points Displays the number of access points in the
standalone mode in the network. The WLAN
Controller does not manage standalone access
points.
Unknown Access
Points Displays the number of access points, which are
detected as unknown.
Table 80. Wireless Global Status/Statistics (Continued)
Field Description
