AT-UWC WLAN Controller Web GUI User’s Guide
280
4. If you want to refresh the display, click Refresh.
Viewing AP
Triangulation
Status
You can view a list of access points that detected the rogue access point.
Based on the information, you can determine the approximate location of
the rogue access point. The AP Triangulation Status page is for rogue
access points only.
To view a list of access points that detected the rogue access point, do the
following:
1. From the Navigation pane, go to WLAN > Intrusion Detection >
Rogue/RF Scan.
The Access Point RF Scan Status page is displayed as shown in
Figure 139 on page 276.
2. Click a MAC address from the Access Point RF Scan Status.
The Access Point RF Scan Status Detail page is displayed as shown in
Figure 140 on page 278.
3. Click the AP Triangulation Status tab.
The AP Triangulation Status page is displayed as shown in Figure 141
on page 281.
Security Mode Displays the security mode that the access point is
using.
802.11n Mode Displays whether or not the access point supports
IEEE 802.11n mode.
Beacon Interval Displays the time interval between sending
beacons.
Highest
Supported Rate Displays the highest supported rate in Mbps that
the access point informs of in the beacon frames.
Peer Managed
AP Displays whether the access point is managed by a
WLAN Controller in the peer group.
Ad hoc Network Displays whether the beacon frames are sent from
the ad hoc network or not.
OUI Description Displays the vendor, manufacturer, or organization
of the access point.
Table 115. Access Point RF Scan Status Detail (Continued)
Field Description
