Chapter 5: Wireless LAN
253
5. Observe the fields described in Table 95.
6. If you want to refresh the display, click Refresh.
Viewing the
Statistics of
Distributed
Tunneling
To view the statistics about the distributed tunnel on the managed access
points, do the following:
1. From the Navigation pane, go to WLAN > Status/Statistics > Managed
AP, click the Statistics tab, then click the Distributed Tunneling subtab.
The Managed Access Point Distributed Tunneling Statistics page is
displayed as shown in Figure 132 on page 254.
Table 95. Managed Access Point VAP Statistics
Field Description
WLAN Packets
Received Displays the number of packets that the VAP has
received from the wireless network.
WLAN Packets
Transmitted Displays the number of packets that the VAP has
transmitted to the wireless network.
WLAN Packets
Receive Dropped Displays the number of packets that the VAP has
received from the wireless network, but discarded.
WLAN Packets
Transmitted
Dropped Displays the number of packets that the VAP has
transmitted to the wireless network, but discarded.
Client
Association
Failure Displays the number of AP clients that the VAP
rejected.
WLAN Bytes
Received Displays the data size in bytes that the VAP has
received from the wireless network.
WLAN Bytes
Transmitted Displays the data size in bytes that the VAP has
transmitted to the wireless network.
WLAN Bytes
Received
Dropped Displays the data size in bytes that the VAP has
received from the wireless network, but discarded.
WLAN Bytes
Transmitted
Dropped Displays the data size in bytes that the VAP has
transmitted to the wireless network, but discarded.
Client
Authentication
Failure Displays the number of AP clients that failed to be
authenticated.
