4.2.9 Current Detection Offset Manual Adjustment Mode cont.

218

7. Press the

and

keys to adjust the

amount of current detection offset.

8. Press

DSPL

SET

to return to the parameter data

display.

9. Press

DATA

ENTER

to return to the parameter setting

mode display. This ends the current detection
offset manual adjustment.

For JUSP-OP03A

1. Press

MODE/SET

to select the parameter setting

mode.

2. Press the

and

DOWN

to select the parameter

number Cn-00.
Parameter Cn-00 is selected when the power is
turned ON.

3. Press

DATA

to display the current data for the pa-

rameter Cn-00.

4. Press the

and

DOWN

keys to change the data

to 08.

5. Press

MODE/SET

to select the current detection off-

set manual adjustment mode.
The amount of current detection offset is dis-
played.

6. Press

DATA

to switch between U-phase and V-

phase current adjustment modes.

7. Press the

and

DOWN

keys to adjust the

amount of current detection offset.

Setting Mode Display

JUSP-OP03A

Setting Mode

Select Cn-00.

Parameter Number

Data

Set to 00-08.

Press

the keys

to
change

the value

Current Detection

Offset Manual

Adjustment Mode

Phase-u

Current

Adjustment

Mode

Phase-v

Current

Adjustment

Mode
